S Spot Recessed Downlight

UGR :

<9

Efficacy (Max) :

94 lm/W

CRI

90+

Aperture Size :

80 mm

Beam Angles :

18º, 31º, 44º, 62º

IP :

IP20

Cutout = Ø112 mm

Illuminate your spaces with precision and efficiency using our advanced LED lighting Fixture. Designed to deliver uniform, homogeneous lighting with minimal spillover, this fixture maximizes lumens output while creating a clean, refined ambiance. Engineered with state-of-the-art Bartenbach optics, this fixture ensures top-tier energy efficiency, providing optimal brightness for any setting. Our LED light?s innovative design also reduces glare, making it ideal for a wide range of applications?from modern workspaces to cozy residential spaces. Upgrade to a lighting solution that combines sleek style with unparalleled performance.

Highly efficient optics

Utilizing advanced LED technology, our lights deliver superior brightness while significantly reducing power usage. This also helps contribute to a greener environment by minimizing carbon footprint.

Degradation free – long life optics

With Alanod Miro Silver (Ultra-Technology) our products gives uniform lighting with highly accurate colours for the longer period of time without risk of ageing and yellowing. This gives pleasant experience of merchandise to the viewer and reduces maintenance expense of the ﬁxture for the merchandiser.

Reduced spillage – more concentrated light

With micro-facet technology, our products achieve a perfect cut-off, minimizing glare and ensuring comfortable illumination. This feature is particularly beneficial in creating visually comfortable spaces.

High CRI 90+

With New Edge patented technology Designed by bartenbach & IT ENSURE 40% more light as compared to conventional fixtures also reducing considerable Glare

Sharp cut-off, minimal spill. lndustry leading optics, crafted in exclusive partnership with Bartenbach

Technical Specifications

Color Temperature (CCT)	Luminaire Dimension	Beam Angle	Wattage	Lumens	UGR	IP Rating	Efficacy	Download TDS
3000K	L 120 x H 131	19°	35W	2988 lm	< 9	IP20	84 lm/W	S Spot Recessed Downlight 3K 35W 19°
3000K	L 120 x H 131	27º	35W	2966 lm	<9	IP20	84 lm/W	S Spot Recessed Downlight 3K 35W 27°
3000K	L 120 x H 131	44º	35W	2724 lm	<9	IP20	77 lm/W	S Spot Recessed Downlight 3K 35W 44°
3000K	L 120 x H 131	61°	35W	2952 lm	<9	IP20	84 lm/W	S Spot Recessed Downlight 3K 35W 61°
3000K	L 120 x H 131	18°	42W	3393 lm	< 18	IP20	81 lm/W	S Spot Recessed Downlight 3K 18º
3000K	L 120 x H 131	31°	42W	3312 lm	< 15	IP20	79 lm/W	S Spot Recessed Downlight 3K 31º
3000K	L 120 x H 131	44°	42W	3097 lm	< 14	IP20	74 lm/W	S Spot Recessed Downlight 3K 44º
3000K	L 120 x H 131	62°	42W	3254 lm	< 20	IP20	78 lm/W	S Spot Recessed Downlight 3K 62º
4000K	L 120 x H 131	19°	36W	3378 lm	<9	IP20	94 lm/W	S Spot Recessed Downlight 4K 36W 19°
4000K	L 120 x H 131	28°	36W	3280 lm	<9	IP20	91 lm/W	S Spot Recessed Downlight 4K 36W 28°
4000K	L 120 x H 131	43°	36W	3137 lm	<9	IP20	87 lm/W	S Spot Recessed Downlight 4K 36W 43°
4000K	L 120 x H 131	61°	36W	3323 lm	<9	IP20	92 lm/W	S Spot Recessed Downlight 4K 36W 61°
4000K	L 120 x H 131	17°	42W	3834 lm	< 17	IP20	94 lm/W	S Spot Recessed Downlight 4K 18°
4000K	L 120 x H 131	43°	41W	3522 lm	< 15	IP20	87 lm/W	S Spot Recessed Downlight 4K 44°
4000K	L 120 x H 131	62°	41W	3615 lm	< 20	IP20	89 lm/W	S Spot Recessed Downlight 4K 62º
